| Material Number | 2836561 |
| ISO Catalog ID | ABD156875R |
| ANSI Catalog ID | ABD156875R |
| Grade | CG5 |
| [DM] Minimum Bore Diameter | 3.962 mm |
| [DM] Minimum Bore Diameter | .156 in |
| [L4] Maximum Boring Depth | 22.225 mm |
| [L4] Maximum Boring Depth | .875 in |
| [L] Overall Length | 38.735 mm |
| [L] Overall Length | 1.525 in |
| [F] F Dimension | 1.854 mm |
| [F] F Dimension | .073 in |
Grades
CG5
A PVD-TiN-coated grade. Straight 9.5% Co substrate. Submicron grain. For general-purpose machining of most steels, stainless steels, high-temperature alloys, titanium, irons, and non-ferrous materials. Performs best at low speeds and will handle interruptions and high feed rates.
